Specifications
Connectivity
Ethernet Ports Yes:1 - 100 Mbit Ethernet Port
Electrical
Power Consumption max 1.5A @ 13.8VDC
Power Consumption typical 1.5A @ 13.8VDC
Recommended Fuse Rating 3A
Supply Voltage 10.8 VDC - 31.2 VDC
Environment
Humidity 60°C, 95% relative humidity (RH) for 18 hours
Operating Temperature Range 5°F to 131°F (-15°C to 55°C )
Shock Vibration 100,000 cycles of 20 G
Storage Temperature Range -22°F to 158°F (-30°C to 70°C )
Waterproofrating IP67
Physical
Dimensions W x H x D Module:8.63" (219.3mm) x 7.56" (192.1mm) x 2.86" (72.9mm)Transducer:5.90" (149.8mm) x 3.24" (82.4mm) x 2.28" (58.0mm)
Mounting Type Module:Surface MountTransducer:Bracket Mount
Weight Module:4.12 lbs (1.86 kg)Transducer:2.67 lbs (1.21 kg)
Other
Interface Ethernet to:HDS LiveHDS CarbonElite FS
Warranty Period 1 Year + 4 additional years ofupgrade optionsTotaling 5 years
